Concrete Laser Screed
Laser-guided machine that levels large concrete floors in one pass.
- Models
- LS-330 · LS-940
- Engine
- Honda GX210 petrol, 3000 W
- Fuel tank
- 40 L
- Working width
- 2.6 m
- Laser
- Leica / Topcon emitter & receiver, Danfoss control
- Finish
- Flat slab, single or double slope
- Mode
- Auto + manual
- Packing size
- 2750 × 1150 × 1250 mm
How it works
A laser on a tripod sets the level for the whole floor. The receiver on the machine reads it and raises or lowers the screed head automatically, so the concrete comes out flat without manual levelling.
Used by Warehouse, factory and parking floor contractors.
